LS Electric Dealer Malaysia

LS ACB

Model Current Rating (Ampere) Breaking Capacity Terminal Bar
AN-06D 630A 65KA Horizontal
AN-08D 800A
AN-10D 1000A
AN-13D 1250A
AN-16D 1600A
AS-20D 2000A 70KA
AS-25E 2500A 85KA Vertical
AS-32E 3200A
AS-40E 4000A
AS-50F 5000A 100KA
AS-63G 6300A 120KA

LS MCCB

Model Amp Pole KA
ABN 52C 15A to 50A 2 Pole 30kA
ABN 62C 60A
ABN 102C 75A to 100A 35kA
ABS 102C 15A to 100A 85kA
ABN 53C 15A-50A 3 Pole 14kA
ABN 63C 60A
ABN 103C 75A to 100A 18kA
ABS 103C 15A to 100A
ABS 103C 125A 37kA
ABS 203C 150A
ABS 203C 175A,200A,225A
ABS 203C 250A
ABN 403C 300A,350A,400A
ABH 53C 15A to 50A 50kA
ABH103C 60A to 125A
ABH 203C 150A, 175A
ABH 203C 200A, 225A
ABH 203C 250A
ABH 403C 300A,350A,400A
ABS 803C 500A to 630A 65kA
ABS 803C 700A to 800A

LS CONTACTOR

Model AC3: 380V – 440V AC 1 Aux Contact
KW HP AMP Rating
MC-9b-11 4 5 9 25 1NO/1NC 240V
MC-12b-11 5.5 7.5 12 27
MC-18b-11 7.5 10 18 32
MC-22b-11 11 15 22 45
MC-32a-11 15 20 32 55
MC-40a-11 18.5 30 40 60
MC-50a-11 22 40 50 100
MC-65a-11 30 50 65 115
MC-75a-11 37 50 75 125
MC-85a-11 45 60 85 135
MC-100a-11 55 75 105 160
MC-130a-11 60 75 130 200
MC-150a-11 75 100 150 250
MC-185a-22 90 125 185 300 2NO/2NC 110V-200V
MC-225a-22 132 150 225 350
MC-265a-22 147 200 265 400
MC-330a-22 160 200 330 500
MC-400a-22 200 300 400 520
MC-500a-22 265 400 500 700 2NO/2NC 200V
MC-630a-22 330 500 630 900
MC-800a-22 440 600 800 1,050
* Special Voltages are 24V, 42V, 48V, 110V, 415V
** Special Voltages are 415V (For MC 185a – MC 800a)

AUXILIARY CONTACT

Model Contact Mounting Type For Contactor
No Nc
UA2-11 1 1 Front Mounting MC-9 TO MC-150
UA2-20 2 0
UA2-02 0 2
UA4-22 2 2
UA4-31 3 1
UA4-40 4 0
UA4-04 0 4
UA1-11 1 1 Side Mounting MC-9 TO MC-150
AU100 1 1 MC-185 TO MC-800

LS Thermal Overload Relay

Model For Contactor Setting Range
Min Med Max
MT-32/3H0.14 MC-9b MC-12b MC-18b MC-22a MC-32a MC-40a 0.1 0.14 0.16
MT-32/3H0.21 0.16 0.21 0.25
MT-32/3H0.33 0.25 0.33 0.4
MT-32/3H0.52 0.4 0.52 0.63
MT-32/3H0.82 0.63 0.82 1
MT-32/3H1.3 1 1.3 1.6
MT-32/3H2.1 1.6 2.1 2.5
MT-32/3H3.3 2.5 3.3 4
MT-32/3H5 4 5 6
MT-32/3H6.5 5 6.5 8
MT-32/3H7.5 6 7.5 9
MT-32/3H8.5 7 8.5 10
MT-32/3H11 9 11 13
MT-32/3H15 12 15 18
MT-32/3H19 16 19 22
MT-32/3H21.5 18 21.5 25
MT-32/3H34 28 34 40
MT-63/3H21.5S MC-50a MC-65a 18 22 25
MT-63/3H30S 24 30 36
MT-63/3H34S 28 34 40
MT-63/3H42S 34 42 50
MT-63/3H55S 45 55 65
MT-95/3H21.5S MC-75a MC-85a MC-100a 18 22 25
MT-95/3H30S 24 30 36
MT-95/3H34S 28 34 40
MT-95/3H42S 34 42 50
MT-95/3H55S 45 55 65
MT-95/3H65S 54 65 75
MT-95/3H74S 63 74 85
MT-95/3H83S 70 83 95
MT-95/3H90S 80 90 100
